FRAME
F-Podium 29 Stealth Air Full Carbon, XCO-optimized Zero Suspension System, 110 mm travel, XC Forward Geometry, upper rocker carbon monoblock, BSA bottom bracket, tapered head tube, internally routed lines and cables (HHG), specific design for single drives , 12 x 148 mm boost rear axle, splash guard for damper, postmount rear brake mount.
Size
S: 410mm/M: 440mm/L: 470mm/XL: 500mm
MUTE
Fox Float SL Performance SV EVOL, 165 x 45 mm. Settings: Compression with 3-way remote control (Open/Medium/Lock), low-speed rebound, air preload. Top trunnion mount, bottom bushings: 30 x 8 mm
DAMPER SETTINGS
Medium compression, medium rebound, air volume spacer 0.4
FORK
Fox 34 Step Cast Float Grip EVOL Performance, 120mm, tapered head tube, 15x110mm Boost Kabolt axle, 44mm offset. Settings: 3-way remote push-to-lock, rebound, air preload
FORK REMOTE
Fox 3 position dual pull, push to lock
TAX RATE
Acros Custom for 1-1/2" head tube, angular contact ball bearings 40 x 52 x 7, internally routed cables and cables
STEM
MDK, 6061-T6 aluminum, 31.8 mm handlebar diameter, angle: +/-5°, length: size S: 50 mm, size M: 50 mm, size L: 60 mm, size XL: 70 mm
HANDLEBAR
ONOFF Sulfur 0.2, double butted 6061 aluminum, rise: 4.8 mm, width: 760 mm, 9° horizontal offset/backsweep, 0° vertical offset/upsweep, 31.8 mm handlebar diameter
HANDLES
ONOFF Twin, single lock-on, 135 mm
SEAT POST
ONOFF Pija telescopic support, internal cable routing, diameter 31.6 mm, universal lever, size S: 405 x 95-125 mm, size M: 458 x 120-150 mm, size L: 498 x 140-170 mm, size XL: 498 x 140-170mm
SADDLE
Fizik Vento Argo X5
FRONT BRAKE
SRAM Level Bronze 2P Stealth, two-piece caliper, one-piece 180mm IS 6-hole centerline brake disc, organic brake pad with steel backplate
REAR BRAKE
SRAM Level Bronze 2P Stealth, two-piece caliper, one-piece 160mm IS 6-hole centerline brake disc, organic brake pad with steel backplate
BRAKE LEVER
SRAM Level Bronze, tool-free reach adjustment, lever joint bushings
RIMS
Mavic CrossMax XL R, 29 Boost, 30 mm internal width, hookless, tubeless ready, 24 spokes
SPOKE
Mavic 24 double butted straight pull spokes
HUB FRONT
Mavic Infinity hub, Boost 15 x 110 mm, IS 6-hole
REAR HUB
Mavic Infinity hub, ID360 freehub technology, Boost 12 x 148 mm, IS 6-bolt, XD freehub
FRONT TIRES
Maxxis Rekon Race 29 x 2.4, EXO Protection, Tubeless Ready, 120 TPI, folding bead
REAR TIRE
Maxxis Rekon Race 29 x 2.4, EXO Protection, Tubeless Ready, 120 TPI, folding bead
CRANKS
SRAM GX Eagle, Boost, DUB axle, direct mount chainring, size S: 170 mm, size M: 175 mm, size L: 175 mm, size XL: 175 mm, chain line 55
CHAINRINGS
34T, CNC machined aluminum, X-SYNC 2
INTERNAL BEARING
SRAM DUB BSA, sealed bearings, 73 mm
CHAIN
SRAM SX Eagle, 12-speed, Powerlock
REAR DERAILLEUR
SRAM GX Eagle, Roller Bearing Clutch Type 3, Cage Lock, 1x12-speed, X-Actuation 1:1
SHIFT LEVER
SRAM GX Eagle, 12-speed
CASSETTE
SRAM XG-1275, 10-52T, 12-speed
DERAILLEUR HANGER
SRAM UDH
WEIGHT
11.9kg
