The ultimate in the Aggressive Series: everything that is noble and good.
Aggressive. Light. Agile. Our R.X375 brings the core of the mountain bike back to E-MTB sport. Made for everyone who loves the driving dynamics and performance of an analog mountain bike, but doesn't want to miss out on an electric drive for extra laps. Agility and liveliness are two core competencies; That's why we made our new trail king R.X375 particularly light.
The latest generation of electric motors from Shimano, the EP8, was installed. It weighs just 2,500g, while offering a whopping 85 Nm and 50% less pedaling resistance - a new benchmark in terms of installation space and weight. In combination with the 375 Wh battery, the R.X375 presents itself as an exceptionally light E-MTB, easy to handle and superior on the single trail. The hand-made full carbon frame made of high modulus fibers (HM) plays a key role in this: with excellent stiffness values and low weight, it forms the basis for spectacular riding fun.
The kinematics and geometry of the AGGRESSIVE SERIES have also been optimized for action. The R.X375 allows more movement in the chassis, for bigger jumps and higher speed; The modern geometry with a flat steering angle and a steep seat angle provides a central, balanced seating position for optimal control. The R.X375 is on the way “Back To The Roots” - more people, less machines.
DETAILS
- Frame & Linkage: Full carbon made from high modulus carbon fibers, handmade
- Suspension fork: 150 mm travel / 110x15 mm / 44 mm axle offset
- Damper: 140 mm travel / 210x50 mm / Trunnion (front bushing) / 19.05 mm (rear bushing)
- Front tire diameter: max. 29x2.4 (755x62)
- Rear tire diameter: max. 29x2.4 (755x62)
- Permitted total weight: 130 kg / ASTM 4
- Motor: Shimano EP8 / 2 driving profiles / up to 85 Nm torque
- Battery: IPU375 / 375 Wh / Carbon / 1.9 kg / Quick Release / 4.5 A charger
- Headset with Blocklock steering stop
Furnishing
| FORK |
FOX 36 FLOAT FACTORY KASHIMA 150MM / FIT4 3-POS ADJUST / E-TUNED |
| MUTE |
FOX FLOAT DPS FACTORY KASHIMA 210X50MM / 3-POS |
| TAX RATE |
ACROS RW375 1.5 HEADSET W/ BLOCKLOCK |
| HANDLEBAR |
ROTWILD B220 CARBON Ø35MM / 15MM RISE / 780MM WIDTH |
| STEM |
ROTWILD S140 AL7075 Ø35MM / 50MM |
| DISPLAY |
SHIMANO EP800 |
| SEAT POST |
EIGHTPINS NGS 2 Ø34.9MM / 25MM OFFSET / 170MM (S) / 190MM (M) / 210MM (L) / 230MM (XL) |
| SADDLE |
ERGON SM PRO |
| HANDLES |
ERGON GD10 SLIM FACTORY FROZEN |
| DRIVE |
SHIMANO EP8 |
| BATTERY |
IPU375 QR CARBON |
| CHARGER |
4.5A CHARGER |
| WHEEL |
CRANKBROTHERS SYNTHESIS ENDURO I9 CARBON (31.5/29.5) / 110-15/148-12 TAS / CL |
| CRANK |
E*THIRTEEN RACE CARBON 160MM (S) / 165MM (M, L) / 170MM (XL) |
| CHAINRING |
E*THIRTEEN DIRECT MOUNT CHAINRING 34T. |
| CHAIN GUIDE |
E*THIRTEEN TRS |
| SHIFT LEVER |
SHIMANO XT I-SPEC EV |
| REAR DERAILLEUR |
SHIMANO XTR 9100 12-SPEED |
| CHAIN |
SHIMANO HG 7100 12-SPEED |
| CASSETTE |
SHIMANO XTR 9100 10-51T. 12-SPEED |
| BRAKE |
SHIMANO XTR 9120 FIN PAD |
| BRAKE DISCS |
SHIMANO RT900/910 SENSOR ICE 203/180 |
| TIRES |
SCHWALBE NOBBY NIC EVO SUPER GROUND TLE SPEEDGRIP 29X2.4 |
| DESIGN TYPE |
FULL SUSPENSION |
| DRIVE TYPE |
E-MTB |
| AREA OF APPLICATION |
TOUR, TRAIL, ENDURO |
| LANDING GEAR |
FOX FACTORY KASHIMA |
| SPRING TRAVEL |
120 TO 140MM, 140 TO 160MM |
| WHEEL SIZE |
29" |
